Products / Airfield Lighting / Approach

IN-AP

LED 12" Unidirectional Inset Approach & Wing Bar Light

Share page in:

Description

APPLICATION
. Approach Centerline & Cross Bars
. Approach Side Rows

COMPLIANCE with :
. ICAO: Annex 14 – Volume I
. IEC: TS 61827
. CAA: Cap 168
. IAAE: TP312

12 Inch Lights IN-App Data Sheet 12 Inch Lights 12 Inch Lights

Dimensions


Length	654_mm
Width	920_mm
Height	312_mm
Max Height ^{with Anchoring Leg}	1000_mm

Main Options

Heater:
electric device, thermostatically controlled, that heats the area near the prisms (inset fixtures) or the external glass lens (elevated fixtures) favoring the melting of the ice and/or snow; thus avoids the light beam obstruction with a behavior similar to a traditional halogen lamp. 20 VA per plug
Monitoring:
an electronic device that returns information of open circuit at the secondary of the isolation transformer in case of failure of a luminous LED source or control board
